Abs Module Bosch Esp 9 9.0 Audi A5
- DiPa Code:
- ABS1294R
- OEM Code:
- 8W0614517M
- Brand:
- DIPA SPORT
- Cod.Cross:
- Condition:
- Remanufactured
Complete ABS Module with Motor Hydraulic Part and Control Unit
Warnings
Send the spare partWITHOUT SUPPORTSandSCREWSattached, we will not be held responsible in case of breakage or loss of the same.
The indicated cost represents the average revision cost for this type of spare part.
The final quote will be formalizedin writingafter evaluation and possible acceptance by the technical department, based on the faults specifically reported in the repair request.
Note Wellthe quote you will receive refersonlyto the defects indicated in the initial request, DIPA will carry out the revision interventionexclusivelyon the reported faults.
In case anyfurther issuesarise during processing, DIPA will promptly inform you, specifying any changes to theprocessing timesand to thequoted amount. Only after yourwritten approvalof such changes will we proceed with the completion of the repair.
Typical Errors and Defects
Typical Defects:
One or more wheels do not brake, brake fluid does not reach the calipers
One or more wheels remain locked
The brake pedal sinks
No communication between ABS and diagnostic system, speed not detected on the instrument panel
The pump motor operates continuously
Error Codes:
C123EF0 - Hydraulic brake booster limit value reached
Hydraulic brake booster limit reached
Limit value reached
Applications
AUDI
AUDI A5 (F53, F5P)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| A5 (F53, F5P) | 2016-06-01 - | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Gasoline | CYMC |
| A5 (F53, F5P) | 2016-06-01 - 2020-02-01 | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DESA |
| A5 (F53, F5P) | 2016-06-01 - 2020-02-01 | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 (F53, F5P) | 2016-06-01 - 2020-02-01 | 1984 cc | 183 KW | 249 HP | 4 Cylinders | Gasoline | CYRC |
| A5 (F53, F5P) | 2016-07-01 - | 2995 cc | 260 KW | 354 HP | 6 Cylinders | Gasoline | CWGD |
| A5 (F53, F5P) | 2016-07-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DESA |
| A5 (F53, F5P) | 2016-07-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 (F53, F5P) | 2016-07-01 - 2018-08-01 | 2967 cc | 160 KW | 218 HP | 6 Cylinders | Diesel | CSWB |
| A5 (F53, F5P) | 2016-09-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Gasoline | CVKB |
| A5 (F53, F5P) | 2016-09-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Gasoline | DKYA |
| A5 (F53, F5P) | 2016-10-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DESA |
| A5 (F53, F5P) | 2016-10-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 (F53, F5P) | 2016-10-01 - 2020-02-01 | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 (F53, F5P) | 2016-11-01 - 2018-08-01 | 2967 cc | 160 KW | 218 HP | 6 Cylinders | Diesel | CSWB |
| A5 (F53, F5P) | 2016-11-01 - 2020-02-01 | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Gasoline | CYRB |
| A5 (F53, F5P) | 2016-11-01 - 2020-02-01 | 1395 cc | 110 KW | 150 HP | 4 Cylinders | Gasoline | CVNA |
| A5 (F53, F5P) | 2017-01-01 - 2020-02-01 | 2967 cc | 210 KW | 286 HP | 6 Cylinders | Diesel | DCPC |
| A5 (F53, F5P) | 2017-02-01 - 2017-12-01 | 2967 cc | 200 KW | 272 HP | 6 Cylinders | Diesel | CRTC |
| A5 (F53, F5P) | 2017-04-01 - | 2894 cc | 331 KW | 450 HP | 6 Cylinders | Gasoline | DECA |
| A5 (F53, F5P) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DKYA |
| A5 (F53, F5P) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DLVA |
| A5 (F53, F5P) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DHDA |
| A5 (F53, F5P) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DEMA |
| A5 (F53, F5P) | 2017-05-01 - 2020-02-01 | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Benzina/Elettrico | DLHB |
| A5 (F53, F5P) | 2017-05-01 - 2020-02-01 | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Benzina/Elettrico | DDWA |
| A5 (F53, F5P) | 2017-05-01 - 2020-02-01 | 1968 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | CZHA |
| A5 (F53, F5P) | 2017-05-01 - 2020-02-01 | 1968 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | DEUA |
| A5 (F53, F5P) | 2018-07-01 - 2020-02-01 | 2967 cc | 170 KW | 231 HP | 6 Cylinders | Diesel | DCPE |
| A5 (F53, F5P) | 2018-07-01 - 2020-02-01 | 1984 cc | 180 KW | 245 HP | 4 Cylinders | Benzina/Elettrico | DKNA |
| A5 (F53, F5P) | 2018-12-01 - 2020-02-01 | 2967 cc | 255 KW | 347 HP | 6 Cylinders | Diesel/Elettrico | DEWB |
| A5 (F53, F5P) | 2019-02-01 - | 1984 cc | 110 KW | 150 HP | 4 Cylinders | Benzina/Elettrico | DMSB |
| A5 (F53, F5P) | 2019-02-01 - | 1984 cc | 110 KW | 150 HP | 4 Cylinders | Benzina/Elettrico | DLVB |
| A5 (F53, F5P) | 2019-10-01 - | 1968 cc | 120 KW | 163 HP | 4 Cylinders | Diesel | DTNA |
| A5 (F53, F5P) | 2019-10-01 - | 1968 cc | 120 KW | 163 HP | 4 Cylinders | Diesel | DEZE |
| A5 (F53, F5P) | 2019-10-01 - | 1984 cc | 195 KW | 265 HP | 4 Cylinders | Benzina/Elettrico | DMTA |
| A5 (F53, F5P) | 2019-10-01 - | 1968 cc | 100 KW | 136 HP | 4 Cylinders | Diesel/Elettrico | DEZB |
| A5 (F53, F5P) | 2019-10-01 - | 1984 cc | 195 KW | 265 HP | 4 Cylinders | Benzina/Elettrico | DPAA |
| A5 (F53, F5P) | 2020-07-01 - | 1984 cc | 150 KW | 204 HP | 4 Cylinders | Benzina/Elettrico | DMSA |
| A5 (F53, F5P) | 2020-09-01 - | 1968 cc | 150 KW | 204 HP | 4 Cylinders | Diesel/Elettrico | DTPA |
AUDI A5 Sportback (F5A, F5F)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| A5 Sportback (F5A, F5F) | 2016-08-01 - 2020-02-01 | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 Sportback (F5A, F5F) | 2016-09-01 - | 2967 cc | 160 KW | 218 HP | 6 Cylinders | Diesel | CSWB |
| A5 Sportback (F5A, F5F) | 2016-09-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 Sportback (F5A, F5F) | 2016-09-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DESA |
| A5 Sportback (F5A, F5F) | 2016-09-01 - | 2995 cc | 260 KW | 354 HP | 6 Cylinders | Gasoline | CWGD |
| A5 Sportback (F5A, F5F) | 2016-09-01 - | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Gasoline | CYMC |
| A5 Sportback (F5A, F5F) | 2016-09-01 - 2020-02-01 | 1984 cc | 183 KW | 249 HP | 4 Cylinders | Gasoline | CYRC |
| A5 Sportback (F5A, F5F) | 2016-09-01 - 2020-02-01 | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 Sportback (F5A, F5F) | 2016-09-01 - 2020-02-01 | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DESA |
| A5 Sportback (F5A, F5F) | 2016-10-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DETA |
| A5 Sportback (F5A, F5F) | 2016-10-01 - | 1968 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DESA |
| A5 Sportback (F5A, F5F) | 2016-11-01 - 2020-02-01 | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Gasoline | CYRB |
| A5 Sportback (F5A, F5F) | 2017-01-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Gasoline | DKYA |
| A5 Sportback (F5A, F5F) | 2017-01-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Gasoline | CVKB |
| A5 Sportback (F5A, F5F) | 2017-01-01 - 2020-02-01 | 1968 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | DEUA |
| A5 Sportback (F5A, F5F) | 2017-01-01 - 2020-02-01 | 1968 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | CZHA |
| A5 Sportback (F5A, F5F) | 2017-01-01 - 2020-02-01 | 1395 cc | 110 KW | 150 HP | 4 Cylinders | Gasoline | CVNA |
| A5 Sportback (F5A, F5F) | 2017-01-01 - 2020-02-01 | 2967 cc | 210 KW | 286 HP | 6 Cylinders | Diesel | DCPC |
| A5 Sportback (F5A, F5F) | 2017-02-01 - | 1984 cc | 125 KW | 170 HP | 4 Cylinders | Benzina/Gas naturale (GNC) | DRXA |
| A5 Sportback (F5A, F5F) | 2017-02-01 - | 1984 cc | 125 KW | 170 HP | 4 Cylinders | Benzina/Gas naturale (GNC) | CVLA |
| A5 Sportback (F5A, F5F) | 2017-02-01 - 2017-12-01 | 2967 cc | 200 KW | 272 HP | 6 Cylinders | Diesel | CRTC |
| A5 Sportback (F5A, F5F) | 2017-02-01 - 2020-02-01 | 1984 cc | 125 KW | 170 HP | 4 Cylinders | Benzina/Gas naturale (GNC) | CVLA |
| A5 Sportback (F5A, F5F) | 2017-03-01 - 2018-08-01 | 2967 cc | 160 KW | 218 HP | 6 Cylinders | Diesel | CSWB |
| A5 Sportback (F5A, F5F) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DKYA |
| A5 Sportback (F5A, F5F) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DLVA |
| A5 Sportback (F5A, F5F) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DHDA |
| A5 Sportback (F5A, F5F) | 2017-05-01 - | 1984 cc | 140 KW | 190 HP | 4 Cylinders | Benzina/Elettrico | DEMA |
| A5 Sportback (F5A, F5F) | 2017-05-01 - 2018-08-01 | 1968 cc | 100 KW | 136 HP | 4 Cylinders | Diesel | DEUB |
| A5 Sportback (F5A, F5F) | 2017-05-01 - 2020-02-01 | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Benzina/Elettrico | DLHB |
| A5 Sportback (F5A, F5F) | 2017-05-01 - 2020-02-01 | 1984 cc | 185 KW | 252 HP | 4 Cylinders | Benzina/Elettrico | DDWA |
| A5 Sportback (F5A, F5F) | 2017-05-01 - 2020-02-01 | 1968 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | DEUA |
| A5 Sportback (F5A, F5F) | 2017-05-01 - 2020-02-01 | 1968 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | CZHA |
| A5 Sportback (F5A, F5F) | 2018-06-01 - | 2894 cc | 331 KW | 450 HP | 6 Cylinders | Gasoline | DECA |
| A5 Sportback (F5A, F5F) | 2018-07-01 - 2020-02-01 | 1984 cc | 180 KW | 245 HP | 4 Cylinders | Benzina/Elettrico | DKNA |
| A5 Sportback (F5A, F5F) | 2018-07-01 - 2020-02-01 | 2967 cc | 170 KW | 231 HP | 6 Cylinders | Diesel | DCPE |
| A5 Sportback (F5A, F5F) | 2018-08-01 - | 1984 cc | 110 KW | 150 HP | 4 Cylinders | Benzina/Elettrico | DMSB |
| A5 Sportback (F5A, F5F) | 2018-08-01 - | 1984 cc | 110 KW | 150 HP | 4 Cylinders | Benzina/Elettrico | DLVB |
| A5 Sportback (F5A, F5F) | 2018-12-01 - 2020-02-01 | 2967 cc | 255 KW | 347 HP | 6 Cylinders | Diesel/Elettrico | DEWB |
| A5 Sportback (F5A, F5F) | 2019-02-01 - 2020-02-01 | 1984 cc | 180 KW | 245 HP | 4 Cylinders | Benzina/Elettrico | DKNA |
| A5 Sportback (F5A, F5F) | 2019-10-01 - | 1968 cc | 120 KW | 163 HP | 4 Cylinders | Diesel | DEZE |
| A5 Sportback (F5A, F5F) | 2019-10-01 - | 1968 cc | 120 KW | 163 HP | 4 Cylinders | Diesel | DTNA |
| A5 Sportback (F5A, F5F) | 2019-10-01 - | 1968 cc | 100 KW | 136 HP | 4 Cylinders | Diesel/Elettrico | DEZB |
| A5 Sportback (F5A, F5F) | 2019-10-01 - | 1984 cc | 195 KW | 265 HP | 4 Cylinders | Benzina/Elettrico | DMTA |
| A5 Sportback (F5A, F5F) | 2020-06-01 - | 1984 cc | 150 KW | 204 HP | 4 Cylinders | Benzina/Elettrico | DMSA |
| A5 Sportback (F5A, F5F) | 2020-09-01 - | 1968 cc | 150 KW | 204 HP | 4 Cylinders | Diesel/Elettrico | DTPA |
