Renault Midlum Magnum Instrument Cluster
- DiPa Code:
- DASH470R
- OEM Code:
- 5010564271D
- Brand:
- DIPA SPORT
- Cod.Cross:
- Condition:
- Remanufactured
Typical Errors and Defects
Typical Defects:
Malfunction of digital display
Applications
RENAULT TRUCKS
RENAULT TRUCKS MAGNUM
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| MAGNUM | 2004-10-01 - 2006-04-01 | 12130 cc | 353 KW | 480 HP | 6 Cylinders | Diesel | DXi 12 |
| MAGNUM | 2004-10-01 - 2006-04-01 | 12130 cc | 324 KW | 441 HP | 6 Cylinders | Diesel | DXi 12 |
| MAGNUM | 2006-05-01 - | 12800 cc | 368 KW | 500 HP | 6 Cylinders | Diesel | DXi 13 |
| MAGNUM | 2006-05-01 - | 12800 cc | 339 KW | 461 HP | 6 Cylinders | Diesel | DXi 13 |
| MAGNUM | 2009-03-01 - | 12800 cc | 353 KW | 480 HP | 6 Cylinders | Diesel | DXi 13 |
| MAGNUM | 2009-03-01 - | 12800 cc | 323 KW | 440 HP | 6 Cylinders | Diesel | DXi 13 |
| MAGNUM | 2009-08-01 - | 12800 cc | 382 KW | 520 HP | 6 Cylinders | Diesel | DXi 13 |
RENAULT TRUCKS MIDLUM
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| MIDLUM | 2000-01-01 - | 4120 cc | 100 KW | 136 HP | 4 Cylinders | Diesel | MIDR 04.02.26 B/4 |
| MIDLUM | 2000-01-01 - | 6177 cc | 184 KW | 250 HP | 6 Cylinders | Diesel | MIDR 06.02.26 Y/41 |
| MIDLUM | 2000-01-01 - | 6177 cc | 154 KW | 209 HP | 6 Cylinders | Diesel | DCI 6-W |
| MIDLUM | 2000-01-01 - | 6177 cc | 154 KW | 209 HP | 6 Cylinders | Diesel | MIDR 06.02.26 W/4 |
| MIDLUM | 2000-01-01 - | 6177 cc | 132 KW | 180 HP | 6 Cylinders | Diesel | MIDR 06.02.26 V/4 |
| MIDLUM | 2000-01-01 - | 4120 cc | 100 KW | 136 HP | 4 Cylinders | Diesel | MIDR 04.02.26 A/4 |
| MIDLUM | 2000-01-01 - | 4120 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | MIDR 04.02.26 B/4 |
| MIDLUM | 2000-01-01 - | 4120 cc | 110 KW | 150 HP | 4 Cylinders | Diesel | DCI 4-B |
| MIDLUM | 2001-10-01 - | 6177 cc | 195 KW | 265 HP | 6 Cylinders | Diesel | DCI 6-A |
| MIDLUM | 2001-10-01 - | 4120 cc | 128 KW | 174 HP | 4 Cylinders | Diesel | DCI 4-C |
| MIDLUM | 2001-10-01 - | 6177 cc | 158 KW | 215 HP | 6 Cylinders | Diesel | DCI 6-W |
| MIDLUM | 2001-10-01 - | 4120 cc | 112 KW | 152 HP | 4 Cylinders | Diesel | DCI 4-B |
| MIDLUM | 2004-04-01 - 2013-12-01 | 7200 cc | 206 KW | 280 HP | 6 Cylinders | Diesel | DXi 7 |
| MIDLUM | 2006-05-01 - | 7200 cc | 206 KW | 280 HP | 6 Cylinders | Diesel | DXi 7 |
| MIDLUM | 2006-05-01 - | 7200 cc | 177 KW | 240 HP | 6 Cylinders | Diesel | DXi 7 |
| MIDLUM | 2006-05-01 - | 4800 cc | 158 KW | 220 HP | 4 Cylinders | Diesel | DXi 5 |
| MIDLUM | 2006-05-01 - | 4800 cc | 140 KW | 190 HP | 4 Cylinders | Diesel | DXi 5 |
| MIDLUM | 2006-05-01 - | 4800 cc | 118 KW | 160 HP | 4 Cylinders | Diesel | DXi 5 |
Techinical Info
The instrument cluster with OE code 5010564271D is a combined instrument panel for Renault Trucks (manufactured by Sagem). It is a complete unit with analog parts and a display and manages the display of the main driving parameters and the status of the vehicle systems, combining dial indicators, warning lights and display sections for messages/alerts.
Technical specifications
- Manufacturer: Sagem
- Complete instrumentation with dial indicators for speedometer, tachometer, fuel level, coolant and oil temperature, brake system pressure. Warning light cluster and digital display for secondary information management.
DIPA can intervene to overhaul these components thanks to its experience and expertise.
Functions
- Display of speed, engine speed and driving information
- Management of control lights and alarms
- Management of messages/alerts on the display
- Interface with the electrical system and vehicle signals to collect data and report statuses (including emergency states)
Model applications
- Renault Trucks Midlum/Magnum
Common faults
- Digital display malfunction
Final conclusions
5010564271D identifies the Renault Trucks instrument cluster (supplied by Sagem) that equips the Midlum and Magnum vehicles.
DIPA has a wide range of spare parts dedicated to the Truck sector, construction vehicles and industrial equipment. In addition, it offers reconditioned components with performance equivalent to new, allowing savings on replacements while contributing to environmental protection through the circular economy. If the spare part you need is not available, don’t worry: DIPA can recondition your part "on demand", restoring full functionality and safety in a short time.
