Ecu Cng Metatron Mf3 Cursor Stralis I II
- DiPa Code:
- EBMETATRON22R
- OEM Code:
- 0069006392
- Brand:
- DIPA SPORT
- Cod.Cross:
- Condition:
- Remanufactured
Applications
FIAT
FIAT DUCATO Autobus (244_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| DUCATO Autobus (244_) | 2003-11-01 - 2006-07-01 | 2799 cc | 90 KW | 122 HP | 4 Cylinders | Diesel | 8140.43 |
IVECO
IVECO STRALIS I
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| STRALIS I | 2008-01-01 - | 7790 cc | 200 KW | 272 HP | Cylinders |
IVECO STRALIS II
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| STRALIS II | 2012-09-01 - | 7790 cc | 200 KW | 272 HP | Cylinders |
Techinical Info
The IVECO OE 504231053 is an engine control unit intended for IVECO/FPT methane-powered applications, belonging to the electronic family Metatron MF3. It is a management module designed to integrate the operation of CNG engines, with particular reference to gas injection logic, ignition, mixture adjustment, and supervision of the main actuators and sensors in the system. This spare part is applicable to the engines of the Cursor 8 CNG family found on Stralis vehicles. It is a specific control unit for industrial engines or buses powered by natural gas, where electronic management must coordinate combustion, gas circuit safety, lambda control, and interaction with various pneumatic and electrical devices present on the vehicle.
Technical characteristics
- Engine control unit for methane/CNG fuel
- Electronic family Metatron MF3
- Typical application on IVECO/FPT Cursor 8 CNG engines
- Dedicated management of gas injection and ignition
- Supervision of the methane circuit solenoids
- Control of signals from pressure, temperature, engine speed, and phase sensors
DIPA can intervene to revise these components thanks to its experience and expertise.
Functionality
- Management of the natural gas injection time based on engine load
- Control of ignition coils and timing
- Adjustment of the mixture in closed loop logic via lambda signal
- Control of the throttle body and response to the accelerator pedal
- Management of the solenoids of the methane system on cylinders and reducer
- Acquisition of gas pressure, gas temperature, air pressure, and engine temperature signals
- Management of adaptive combustion parameters
- Supervision of the wastegate control on turbocharged applications
- Diagnostics of the engine system and storage of anomalies
- General control of the CNG engine operation under all operating conditions
Model applications
- IVECO Stralis CNG
Typical defects
- The control unit does not communicate with the diagnostic tool
- Engine failure to start
- Sudden shutdowns or irregular operation
Final conclusions
The IVECO OE 504231053 is an ECU for CNG applications, belonging to the Metatron MF3 family, intended for the complete management of IVECO/FPT methane-powered engines, with particular association to the Cursor 8 CNG units. Its task is to control injection, ignition, mixture adjustment, gas circuit actuators, and signals from the main engine sensors.
DIPA has a wide range of spare parts dedicated to the Truck world, construction vehicles, and industrial equipment. Not only that: it has refurbished components with performance equal to new, allowing for savings in replacement while contributing to environmental protection through the circular economy. If the spare part you need is not available, don't worry: DIPA can refurbish your part “on demand,” restoring its full functionality and safety in a short time.
