Revision of EBS Brake Module Daf XF 95

DiPa Code:
EBS023R
OEM Code:
1650470
Brand:
DIPA SPORT
Condition:
Remanufactured
Dynamic Brake Control Unit
To view availability and prices, login or register
Are you a private individual? Find out how we can help you
Applications
DAF
DAF XF 95
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
XF 95 2002-01-01 - 2006-03-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2002-01-01 - 2006-03-01 12580 cc 315 KW 430 HP Cylinders
XF 95 2002-01-01 - 2006-03-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 315 KW 430 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 355 KW 480 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 315 KW 428 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2002-09-01 - 2006-03-01 12580 cc 390 KW 530 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 315 KW 428 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 390 KW 530 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 315 KW 430 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 315 KW 428 HP Cylinders
FIAT
FIAT DOBLO Cargo (263_)
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
DOBLO Cargo (263_) 2010-02-01 - 2023-12-01 1598 cc 66 KW 90 HP 4 Cylinders Diesel 463 46 020
DOBLO Cargo (263_) 2010-02-01 - 2023-12-01 1598 cc 66 KW 90 HP 4 Cylinders Diesel 263 A5.000
DOBLO Cargo (263_) 2010-02-01 - 2023-12-01 1598 cc 66 KW 90 HP 4 Cylinders Diesel 263 A4.000
MAHINDRA
MAHINDRA CHAMPION Pianale piatto/Telaio
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
CHAMPION Pianale piatto/Telaio 2001-06-01 - 2016-12-01 510 cc 7 KW 10 HP 1 Cylinders Diesel M510
RENAULT, RENAULT KOREA
RENAULT, RENAULT KOREA MASTER II Autobus (JD)
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
MASTER II Autobus (JD) 1998-07-01 - 2001-01-01 2499 cc 59 KW 80 HP 4 Cylinders Diesel S8U 772
MASTER II Autobus (JD) 1998-07-01 - 2001-01-01 2499 cc 59 KW 80 HP 4 Cylinders Diesel S8U 770
MASTER II Autobus (JD) 1998-07-01 - 2001-10-01 2799 cc 84 KW 114 HP 4 Cylinders Diesel S9W 700
MASTER II Autobus (JD) 1998-07-01 - 2001-10-01 2799 cc 84 KW 114 HP 4 Cylinders Diesel S9W 702
VW
VW TRANSPORTER T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ, EUROVAN / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, KOMBI / MICROBUS / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK,, TRANSPORTER / CARAVELLE Mk IV Autobus (70B, 70C, 7DB, 7DK, 7, TRANSPORTER / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7 1998-05-01 - 2003-04-01 2461 cc 111 KW 151 HP 5 Cylinders Diesel AXG
CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ, EUROVAN / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, KOMBI / MICROBUS / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK,, TRANSPORTER / CARAVELLE Mk IV Autobus (70B, 70C, 7DB, 7DK, 7, TRANSPORTER / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7 1998-05-01 - 2003-04-01 2461 cc 111 KW 151 HP 5 Cylinders Diesel AHY
Techinical Info

The DAF control unit code OE 1650470 is an electronic module of the EBS system intended for DAF industrial vehicles.

It is an ECU dedicated to the electronic management of braking. Its task is to process the signals from the braking system, coordinate the ABS/EBS logics, communicate with the modulators and other electronic devices of the vehicle, and manage the braking response more quickly and accurately than a purely pneumatic system.

This unit is primarily mounted or associated with DAF XF series vehicles.

Technical characteristics

  • Electronic control unit: EBS ZM
  • Manufacturer: WABCO
  • Name: EBS Electronic Control Unit
  • Interface with wheel sensors, modulators, and vehicle network
  • Typical power supply from industrial vehicle 24 V

DIPA can intervene to revise these components thanks to its experience and expertise.

Functionality

  • Electronic management of service braking
  • Processing of signals from wheel speed sensors
  • Control of ABS functions
  • Management of EBS logic with faster braking command
  • Communication with modulators and valves of the braking system
  • Data exchange with other electronic systems of the vehicle
  • Storage of brake system anomalies
  • Support for electronic diagnosis of the braking circuit
  • Coordination of braking based on vehicle configuration
  • Contribution to stability and dynamics logics of the vehicle, based on the installed equipment

Model applications

  • DAF XF

Typical defects

  • The control unit does not communicate with the diagnostic tool
  • EBS or ABS warning lights on
  • Irregular braking

Final conclusions

The EBS DAF OE 1650470 control unit is an ECU of the electronic braking system used on various DAF industrial vehicles. It is a fundamental component for the proper functioning of EBS, ABS, and dynamic braking management, and works closely with wheel sensors, modulators, valves, and the vehicle's electronic network.

DIPA has a wide range of spare parts dedicated to the Truck world, construction vehicles, and industrial equipment. Not only that: it has refurbished components with performance equal to new, which allows for savings in replacement while contributing to environmental protection through the circular economy. If the spare part you need is not available, don't worry: DIPA can refurbish your part “on demand,” restoring its full functionality and safety in a short time.
