Repair of EBS Brake Module Daf XF 95

DiPa Code:
EBS024R
OEM Code:
4461350390
Brand:
DIPA SPORT
Condition:
Remanufactured
Dynamic Brake Control Unit
To view availability and prices, login or register
Are you a private individual? Find out how we can help you
Applications
DAF
DAF XF 95
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
XF 95 2002-01-01 - 2006-03-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2002-01-01 - 2006-03-01 12580 cc 315 KW 430 HP Cylinders
XF 95 2002-01-01 - 2006-03-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 315 KW 430 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 355 KW 480 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 315 KW 428 HP Cylinders
XF 95 2002-01-01 - 2006-12-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2002-09-01 - 2006-03-01 12580 cc 390 KW 530 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 315 KW 428 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 390 KW 530 HP Cylinders
XF 95 2002-09-01 - 2006-12-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 315 KW 430 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 280 KW 381 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 355 KW 483 HP Cylinders
XF 95 2005-12-01 - 2006-12-01 12580 cc 315 KW 428 HP Cylinders
FIAT
FIAT DOBLO Cargo (263_)
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
DOBLO Cargo (263_) 2010-02-01 - 2023-12-01 1598 cc 66 KW 90 HP 4 Cylinders Diesel 463 46 020
DOBLO Cargo (263_) 2010-02-01 - 2023-12-01 1598 cc 66 KW 90 HP 4 Cylinders Diesel 263 A5.000
DOBLO Cargo (263_) 2010-02-01 - 2023-12-01 1598 cc 66 KW 90 HP 4 Cylinders Diesel 263 A4.000
MAHINDRA
MAHINDRA CHAMPION Pianale piatto/Telaio
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
CHAMPION Pianale piatto/Telaio 2001-06-01 - 2016-12-01 510 cc 7 KW 10 HP 1 Cylinders Diesel M510
RENAULT, RENAULT KOREA
RENAULT, RENAULT KOREA MASTER II Autobus (JD)
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
MASTER II Autobus (JD) 1998-07-01 - 2001-01-01 2499 cc 59 KW 80 HP 4 Cylinders Diesel S8U 772
MASTER II Autobus (JD) 1998-07-01 - 2001-01-01 2499 cc 59 KW 80 HP 4 Cylinders Diesel S8U 770
MASTER II Autobus (JD) 1998-07-01 - 2001-10-01 2799 cc 84 KW 114 HP 4 Cylinders Diesel S9W 700
MASTER II Autobus (JD) 1998-07-01 - 2001-10-01 2799 cc 84 KW 114 HP 4 Cylinders Diesel S9W 702
VW
VW TRANSPORTER T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ, EUROVAN / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, KOMBI / MICROBUS / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK,, TRANSPORTER / CARAVELLE Mk IV Autobus (70B, 70C, 7DB, 7DK, 7, TRANSPORTER / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7 1998-05-01 - 2003-04-01 2461 cc 111 KW 151 HP 5 Cylinders Diesel AXG
CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, 7DC, 7DJ, EUROVAN / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK, 70J, 70K, KOMBI / MICROBUS / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7DK,, TRANSPORTER / CARAVELLE Mk IV Autobus (70B, 70C, 7DB, 7DK, 7, TRANSPORTER / CARAVELLE T4 Autobus (70B, 70C, 7DB, 7 1998-05-01 - 2003-04-01 2461 cc 111 KW 151 HP 5 Cylinders Diesel AHY
Techinical Info

The control unit with code DAF OE 4461350390 is an EBS (Electronic Braking System) control unit used on DAF commercial vehicles with a WABCO-supplied electronic braking system. The unit processes the braking request, manages safety logics (ABS and related functions) and controls the electro-pneumatic modulation of braking pressure on the different axles, coordinating with other onboard control units via the vehicle's communication network.

Technical specifications

  • Type: EBS for an electronically controlled pneumatic braking system.
  • System family: WABCO EBS3 (electronic brake control unit for commercial vehicles).
  • Catalog dimensional data: dimensions: approx. 180 × 135 × 45 mm
  • Gross weight: approx. 0.466 kg
  • System integration: management of signals and actuations related to wheel speed sensors, brake requests, circuit pressure and commands to modulators/electropneumatic valves (system configuration depends on vehicle and equipment).

DIPA can intervene to overhaul these components thanks to its experience and expertise.

Functions

  • Electronic transmission of the deceleration request and reduced braking response times compared to conventional systems.
  • Typical EBS functions: braking control and brake force distribution; anti-lock (ABS) and stability/traction management (functions dependent on configuration); management of comfort and safety logics.
  • Integrated diagnostics: self-diagnosis, fault memory and degraded mode management in case of anomaly.

Applicable models

  • DAF XF

Typical faults

  • No communication/diagnosis with the ESP unit possible
  • Loss of full functionality, intermittent or permanent
  • Incorrect battery voltage value detected

Error codes:
060601 - Unit A10B detected undervoltage or short to ground
060604 - Unit A10B detected undervoltage or short to ground
18F0FF - ESP function limitation
220303 - Short to positive, ABS solenoids left/right front axle
730201 - The power supply of unit A10B is too low
75020C - Internal fault

Final conclusions

The DAF OE 4461350390 is a WABCO EBS (EBS3) control unit used on the DAF XF.
