EBS Control Unit Renault Trucks Premium 2
- DiPa Code:
- EBS029R
- OEM Code:
- 0486106080
- Brand:
- KNORR BREMSE
- Cod.Cross:
- Condition:
- Remanufactured
Typical Errors and Defects
Applications
FIAT
FIAT SCUDO Furgone (220_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| SCUDO Furgone (220_) | 1999-05-01 - 2006-12-01 | 1997 cc | 80 KW | 109 HP | 4 Cylinders | Diesel | RHW (DW10ATED4) |
| SCUDO Furgone (220_) | 1999-05-01 - 2006-12-01 | 1997 cc | 80 KW | 109 HP | 4 Cylinders | Diesel | RHM (DW10ATED4) |
| SCUDO Furgone (220_) | 1999-05-01 - 2006-12-01 | 1997 cc | 80 KW | 109 HP | 4 Cylinders | Diesel | RHK (DW10UTED4) |
PEUGEOT
PEUGEOT PARTNER Cassone/Limousine spaziosa (5_, G_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| PARTNER Cassone/Limousine spaziosa (5_, G_), PARTNER FURGON Cassone/Limousine spaziosa (5_, G_), PARTNER Van (5_, G_), RANCH Cassone/Limousine spaziosa (5_, G_) | 2000-09-01 - 2002-10-01 | 1587 cc | 80 KW | 109 HP | 4 Cylinders | Benzina/Etanolo | NFU (TU5JP4) |
RENAULT TRUCKS
RENAULT TRUCKS PREMIUM 2
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| PREMIUM 2 | 2005-10-01 - | 10837 cc | 243 KW | 330 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 7146 cc | 206 KW | 280 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 10837 cc | 324 KW | 440 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 10837 cc | 302 KW | 411 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 10837 cc | 331 KW | 450 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 10837 cc | 302 KW | 410 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 10837 cc | 272 KW | 370 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - | 7146 cc | 235 KW | 320 HP | Cylinders | ||
| PREMIUM 2 | 2005-10-01 - 2007-02-01 | 11123 cc | 309 KW | 420 HP | Cylinders | ||
| PREMIUM 2 | 2006-01-01 - 2008-05-01 | 11123 cc | 235 KW | 320 HP | Cylinders | ||
| PREMIUM 2 | 2006-05-01 - | 7146 cc | 235 KW | 320 HP | Cylinders | ||
| PREMIUM 2 | 2006-05-01 - | 7146 cc | 177 KW | 241 HP | Cylinders | ||
| PREMIUM 2 | 2006-10-01 - | 10837 cc | 280 KW | 381 HP | Cylinders | ||
| PREMIUM 2 | 2006-10-01 - | 10837 cc | 339 KW | 460 HP | Cylinders | ||
| PREMIUM 2 | 2006-10-01 - | 10837 cc | 316 KW | 430 HP | Cylinders | ||
| PREMIUM 2 | 2006-10-01 - | 7146 cc | 247 KW | 340 HP | Cylinders | ||
| PREMIUM 2 | 2006-10-01 - | 7146 cc | 224 KW | 310 HP | Cylinders | ||
| PREMIUM 2 | 2006-10-01 - | 7146 cc | 194 KW | 264 HP | Cylinders | ||
| PREMIUM 2 | 2007-02-01 - | 10837 cc | 323 KW | 439 HP | Cylinders | ||
| PREMIUM 2 | 2007-04-01 - 2008-05-01 | 10837 cc | 243 KW | 330 HP | Cylinders | ||
| PREMIUM 2 | 2008-06-01 - 2013-04-01 | 7146 cc | 206 KW | 280 HP | Cylinders | ||
| PREMIUM 2 | 2009-02-01 - | 7146 cc | 235 KW | 320 HP | Cylinders |
VW
VW TRANSPORTER T3 Furgone (24_, 25_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| TRANSPORTER / KOMBI T3 Furgone (24_, 25_), TRANSPORTER T3 Furgone (24_, 25_), VANAGON T3 Furgone (24_, 25_) | 1983-08-01 - 1989-02-01 | 1913 cc | 66 KW | 90 HP | 4 Cylinders | Gasoline | GW |
Techinical Info
The control unit 20777347 is an electronic control unit of the EBS (Electronic Braking System) used on various commercial vehicles Renault Trucks (and in many applications shared with Volvo platforms). Basically, it is the brain of the EBS: it receives signals from sensors and brake controls, processes them and drives the electro-pneumatic modules that generate and regulate braking pressure at the wheels, also managing safety functions (ABS/ASR and related features, depending on the configuration).
This control unit is part of the Knorr-Bremse EBS 5 generation (EBS5 / 5.x), where the ECU works on a network with EPM (electro-pneumatic) modules, modulators/valves.
Technical features
- Electronic control unit for EBS 5 (architecture for 24 V commercial vehicles).
- Vehicle network communication via CAN (typically J1939 and EBS/auxiliary dedicated networks, depending on wiring and vehicle).
- Management of inputs from wheel speed sensors, pedal/valve brake command signals, pressure sensors (where present) and system states.
- Control outputs to EPM electro-pneumatic modules, solenoid valves/modulators and actuators connected to the braking circuit.
DIPA can intervene to overhaul these components thanks to its experience and expertise.
Functions
- Electronic management of service braking with reduced response times and more precise modulation compared to purely pneumatic logic.
- ABS (anti-lock) functions and traction slip control ASR (if provided in the configuration).
- Distribution and regulation of braking based on dynamic conditions and available signals (load/pressures/configuration).
- Coordination with the vehicle network and any related functions (stability, trailer management, indicator lights and warnings, depending on configuration).
Model applications
- Renault Trucks Premium 2
Common faults
- The control unit does not communicate with the diagnostic tool.
- The control unit exhibits intermittent malfunctions.
- Fault/warning light on the instrument cluster.
Final conclusions
The Knorr-Bremse unit for Renault Trucks with OE code 20777347 is an EBS control unit of the EBS 5 generation that governs the main functions of the electronic braking system on Renault commercial vehicles.
DIPA has a wide range of spare parts dedicated to the Truck world, construction vehicles and industrial equipment. Not only that: it has reconditioned components with performance equivalent to new, which make savings on replacements possible while contributing to environmental protection thanks to the circular economy. If the spare part you need is not available, don't worry: DIPA can overhaul "on demand" your part, restoring its full functionality and safety in a short time.
