EBS Brake Control Unit for Renault Premium 420

Typical faults:
The control unit does not communicate with the diagnostic tool
Warning light illuminated on the instrument cluster

The EBS control unit with code OE Renault 5010457367 is the electronic control unit of the electronic braking system on Renault Trucks commercial vehicles equipped with the Knorr-Bremse EBS architecture. Its function is to manage the driver’s braking request, process sensor signals (wheel/pressure/system) and command the electro-pneumatic modules that modulate pressure to the brakes, including ABS logic and stability/trailer integration functions when provided by the vehicle configuration.

Technical specifications

• Type: EBS (Electronic Control Unit) for an electronically managed pneumatic braking system on a commercial vehicle.
• Reference system: also identified as EBS 2.2 within the EBS family for Renault Trucks tractor units.
• Power supply: typical commercial vehicle network 24 V (diagnostic management and protections related to voltage drops/irregularities).
• Communications: management over the vehicle network (CAN) to brake modules and, if present, trailer management via a dedicated network/industry-standard connection.
• Main interfaces (depending on system configuration): braking request input from the brake pedal module (FBM) or equivalent sensors; wheel speed sensor signals (ABS logic); pressure/pressure switch signals from pneumatic circuits; handling of signals related to brake wear and, when provided, dynamic sensors (yaw/steering angle) for stability functions.

DIPA can intervene to overhaul these components thanks to its experience and expertise.

Functions

• Electronic brake management with rapid and coordinated modulation of brake pressure.
• Integration of ABS functions through evaluation of wheel speeds and control of the electro-pneumatic modules.
• Management and balancing of braking between axles/wheels according to vehicle configuration.
• Coordination with trailer control (if present) to reduce push/pull forces and improve braking stability.
• System diagnostics: fault logging, power supply monitoring, sensor consistency and network communications.

Model applications

• Renault Trucks Premium

Common faults

• The control unit does not communicate with the diagnostic tool
• Warning light on the instrument panel

Final conclusions

The 5010457367 is an EBS Renault Trucks control unit used on platforms.

DIPA has a wide range of spare parts dedicated to the Truck sector, construction vehicles and industrial equipment. Not only that: it offers reconditioned components with performance equal to new, which allow savings when replacing parts while contributing to environmental protection through the circular economy. If the spare part you need is not available, don’t worry: DIPA can recondition your part “on demand,” restoring its full functionality and safety in a short time.
