ECU EDC MS 6.3 Truck DongFeng DFL 4

DiPa Code:
EDEDCMS63043R
OEM Code:
0281020043
Brand:
DIPA SPORT
Condition:
Remanufactured
Engine Control Unit
To view availability and prices, login or register
Are you a private individual? Find out how we can help you
Applications
DONGFENG
DONGFENG KINLAND
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
KINLAND 2007-06-01 - 6690 cc 180 KW 245 HP Cylinders
KINLAND 2007-06-01 - 8849 cc 231 KW 314 HP Cylinders
KINLAND 2007-06-01 - 6690 cc 169 KW 230 HP Cylinders
KINLAND 2007-06-01 - 6690 cc 198 KW 269 HP Cylinders
KINLAND 2009-01-01 - 8849 cc 276 KW 375 HP Cylinders
DONGFENG TIANLONG
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
TIANLONG 2006-05-01 - 8849 cc 280 KW 381 HP Cylinders
TIANLONG 2006-05-01 - 11120 cc 257 KW 349 HP Cylinders
TIANLONG 2006-05-01 - 2014-12-01 11123 cc 276 KW 375 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 8849 cc 213 KW 290 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 11123 cc 276 KW 375 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 11123 cc 250 KW 340 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 8849 cc 276 KW 375 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 8900 cc 232 KW 315 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 11120 cc 213 KW 290 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 8849 cc 250 KW 340 HP Cylinders
TIANLONG 2008-01-01 - 2013-12-01 8849 cc 231 KW 314 HP Cylinders
TIANLONG 2008-01-01 - 2017-12-01 8849 cc 250 KW 340 HP Cylinders
TIANLONG 2008-05-01 - 2017-12-01 11123 cc 303 KW 412 HP Cylinders
TIANLONG 2009-01-01 - 2013-12-01 11123 cc 276 KW 375 HP Cylinders
TIANLONG 2010-01-01 - 2018-12-01 11123 cc 283 KW 385 HP Cylinders
TIANLONG 2010-01-01 - 2021-12-01 11123 cc 257 KW 349 HP Cylinders
TIANLONG 2011-01-01 - 2016-12-01 12981 cc 331 KW 450 HP Cylinders
TIANLONG 2011-01-01 - 2016-12-01 11123 cc 303 KW 412 HP Cylinders
TIANLONG 2011-01-01 - 2016-12-01 12981 cc 335 KW 455 HP Cylinders
TIANLONG 2012-01-01 - 2015-12-01 9466 cc 250 KW 340 HP Cylinders
TIANLONG 2012-01-01 - 2015-12-01 9466 cc 232 KW 315 HP Cylinders
TIANLONG 2012-01-01 - 2017-12-01 11123 cc 283 KW 385 HP Cylinders
TIANLONG 2012-01-01 - 2017-12-01 9466 cc 268 KW 364 HP Cylinders
TIANLONG 2012-01-01 - 2017-12-01 11123 cc 257 KW 349 HP Cylinders
HYUNDAI
HYUNDAI HIGHWAY VAN
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
HIGHWAY VAN 2000-03-01 - 2004-03-01 2656 cc 127 KW 173 HP 6 Cylinders Gasoline G6BA
HIGHWAY VAN 2000-03-01 - 2004-03-01 1997 cc 100 KW 136 HP 4 Cylinders Gasoline G4JP
VW
VW KOMBI T2 Autobus (22, 7X)
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
COMBI T2 Autobus (22, 7X), KOMBI T2 Autobus (22, 7X) 1992-07-01 - 2000-07-01 1595 cc 64 KW 87 HP 4 Cylinders Gasoline 1UF
Techinical Info

The control unit with code OE 5010550800 is an EDC diesel engine management module used on DongFeng platforms Kinland and Tianlong with six-cylinder engines of various displacements. The unit is a Bosch from the EDC MS6.3 family, used for full management of injection, torque strategies and engine protections.

Technical characteristics

  • Type: engine control unit (EDC)
  • Platform: Bosch EDC MS6.3
  • Configuration: module application-specific
  • Connectivity: integration with the vehicle system via multi-connector wiring; on some units there are 2 rectangular connectors with a dedicated pin configuration

DIPA can intervene to overhaul these components thanks to its experience and expertise.

Functionalities

  • Management of injection quantity and strategies during starting, idle and transients
  • Control of fuel pressure and regulation/limitation logics for safety
  • Management of torque request (torque limits and engine protections)
  • Sensor plausibility validation (rpm/phase, temperatures, pressures) with activation of substitute values in case of failure
  • Diagnostics with fault logging and recovery modes when critical parameters are out of range

Model applications

  • DONGFENG Kinland/Tianlong

Typical faults

  • Failure to start or starting followed by immediate shut-off
  • No diagnostic communication or intermittent communication
  • Recovery with torque limitation and reduced accelerator response

Final conclusions

The control unit OE 5010550800 is an engine ECU Bosch EDC MS6.3, fitted on DONGFENG Kinland/Tianlong applications.

DIPA has a wide range of spare parts dedicated to the Truck sector, construction vehicles and industrial equipment. Not only that: it offers rebuilt components with performance equivalent to new ones, which allow savings on replacement while contributing to environmental protection through the circular economy. If the spare part you need is not available, don’t worry: DIPA can overhaul your part "on demand", restoring full functionality and safety in a short time.
