Bosch Ecu Edc Ms 6.4-5.1 Man M 2000 L

DiPa Code:
EDEDCMS6451347R
OEM Code:
350141
Brand:
DIPA SPORT
Condition:
Remanufactured
Engine Control Unit
To view availability and prices, login or register
Are you a private individual? Find out how we can help you
Applications
MAN
MAN M 2000 L
Model Year of Production Displacement KW HP Cylinders Fuel Type Engine Code
M 2000 L 1995-03-01 - 2007-02-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 03
M 2000 L 1995-03-01 - 2007-02-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 01
M 2000 L 1995-03-01 - 2007-02-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 06
M 2000 L 1995-04-01 - 2006-08-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 03
M 2000 L 1995-04-01 - 2006-08-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 01
M 2000 L 1995-04-01 - 2006-08-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 06
M 2000 L 1995-05-01 - 2002-04-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 03
M 2000 L 1995-05-01 - 2002-04-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 01
M 2000 L 1995-05-01 - 2002-04-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 06
M 2000 L 1995-05-01 - 2007-02-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 03
M 2000 L 1995-05-01 - 2007-02-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 01
M 2000 L 1995-05-01 - 2007-02-01 6871 cc 206 KW 280 HP 6 Cylinders Diesel D 0836 LFL 06
Techinical Info

The engine control unit Bosch EDC with OE code 350141 is an electronic diesel engine management unit used in MAN commercial vehicles.

This is an ECU intended for the complete control of diesel engine operation, managing signals from the main operating sensors and commanding injection strategies, idle regulation, engine protection, self-diagnosis and emergency modes. In this family of control units, the installed software plays a decisive role because it can vary depending on the engine, power, vehicle configuration and system generation.

Technical characteristics

  • Type: diesel engine control unit EDC
  • System manufacturer: Bosch
  • Engines: MAN D0836, with possible application variants also related to similar versions
  • System equipped with self-diagnosis logic
  • Emergency operating modes in case of sensor anomalies or management faults
  • Integration of internal ECU sensors, including the atmospheric pressure sensor in configurations provided by this management family

DIPA can intervene to overhaul these components thanks to its experience and expertise.

Functions

  • Acquires the engine speed signal
  • Processes signals related to boost pressure
  • Manages engine temperature and intake air temperature values
  • Controls the injection logic according to load and operating conditions
  • Regulates idle speed and intermediate operating conditions
  • Controls engine and turbocharger protection strategies
  • Stores system faults via self-diagnosis
  • Activates recovery or emergency modes in the presence of faults on sensors, power supplies or internal circuits

Model applications

  • MAN M2000

Typical faults

  • Engine shutdown/difficulty starting
  • Irregular engine operation
  • The control unit goes into recovery

Final conclusions

The engine control unit Bosch EDC OE code 350141 is used on several MAN commercial vehicles and is particularly associated with engines of the D0836 family. It is a complete diesel ECU designed to manage the main engine parameters, with regulation, diagnostic and recovery functions.

DIPA has a wide range of spare parts dedicated to the Truck sector, construction vehicles and industrial equipment. Not only that: it offers refurbished components with performance equivalent to new, allowing savings when replacing parts and contributing to environmental protection through the circular economy. If the spare part you need is not available, don’t worry: DIPA can overhaul your part on demand, restoring full functionality and safety in a short time.
