Ecu S8 Scania Series L P G R S S520 R520
- DiPa Code:
- EDEMSS8004R
- OEM Code:
- 2277671
- Brand:
- DIPA SPORT
- Cod.Cross:
- Condition:
- Remanufactured
Applications
CITROËN
CITROËN BERLINGO Cassone/Limousine spaziosa (B9)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| BERLINGO Cassone/Limousine spaziosa (B9) | 2008-04-01 - | 1560 cc | 80 KW | 109 HP | 4 Cylinders | Diesel | 9HZ (DV6TED4) |
SCANIA
SCANIA R II
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| R II | 2016-09-01 - | 16353 cc | 382 KW | 520 HP | Cylinders | ||
| R II | 2016-09-01 - | 16353 cc | 382 KW | 519 HP | Cylinders |
SCANIA S
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| S | 2016-09-01 - | 16353 cc | 382 KW | 520 HP | Cylinders | ||
| S | 2016-09-01 - | 16353 cc | 382 KW | 519 HP | Cylinders | ||
| S | 2016-09-01 - | 16353 cc | 383 KW | 521 HP | Cylinders |
TOYOTA
TOYOTA HIACE IV Furgone (_H1_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| HIACE / REGIUS ACE IV Furgone (_H1_), HIACE IV Furgone (_H1_) | 1989-08-01 - 2000-08-01 | 2779 cc | 61 KW | 83 HP | 4 Cylinders | Diesel | 3L |
Techinical Info
The Scania control unit with OE code 193090126 is an engine management unit belonging to the EMS S8 family, used on Scania commercial vehicles in particular for the L, P, G, R and S series.
This is a diesel engine command unit designed for complete propulsion management, with control of injection, processing of sensor signals, management of requested torque, control of engine protection strategies and interfacing with the vehicle's electronic network. In Scania applications, the EMS S8 system is linked to engines with XPI technology, i.e. an advanced engine management intended for heavy-duty engines and high-power Euro 6 applications.
Technical characteristics
- Component type: diesel engine management unit
- System family: Scania EMS S8
- Manufacturer: Continental / Siemens VDO
- Engines: Scania V8 family DC16
- Vehicle electrical system voltage: 24 V
- Control unit integrated into the vehicle electronic network via CAN communication
DIPA can intervene to overhaul these components thanks to its experience and expertise.
Functions
- Manages the amount of fuel and the injection logic
- Processes the accelerator pedal signal and the torque request
- Acquires temperature, pressure and engine speed signals
- Manages boost and performance control parameters
- Oversees the signals required for the correct operation of the emissions system
- Communicates with other vehicle modules via the CAN network
- Performs continuous diagnostics on sensors and connected circuits
- Activates power limiting or recovery strategies in case of anomalies
- Participates in engine shutdown and protection logic in the presence of critical faults
Model applications
- Scania series L/P/G/R/S
Typical faults
- The control unit does not communicate with the diagnostic tool
- The control unit goes into recovery/engine performance limited
- No start or irregular operation
Final conclusions
The control unit Scania OE code 193090126 belongs to the EMS S8 family and is associated with L, P, G, R and S series vehicles equipped with high-performance DC16 engines. It is an advanced engine management module intended for diesel systems with XPI injection, CAN network and advanced diagnostics.
DIPA has a wide range of spare parts dedicated to the Truck sector, construction vehicles and industrial equipment. Not only that: it offers refurbished components with performance equivalent to new, allowing savings when replacing parts and contributing to environmental protection through the circular economy. If the spare part you need is not available, don’t worry: DIPA can overhaul your part on demand, restoring full functionality and safety in a short time.
