Ecu S8 Scania Series P G R T 410
- DiPa Code:
- EDEMSS8005R
- OEM Code:
- 242400307
- Brand:
- DIPA SPORT
- Cod.Cross:
- Condition:
- Remanufactured
Applications
NISSAN
NISSAN INTERSTAR Furgone (X70)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| INTERSTAR Furgone (X70) | 2006-04-01 - | 2463 cc | 74 KW | 101 HP | 4 Cylinders | Diesel | G9U 720 |
| INTERSTAR Furgone (X70) | 2006-04-01 - | 2463 cc | 74 KW | 101 HP | 4 Cylinders | Diesel | G9U 754 |
NISSAN INTERSTAR Pianale piatto/Telaio (X70)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| INTERSTAR Pianale piatto/Telaio (X70) | 2004-02-01 - | 2463 cc | 73 KW | 99 HP | 4 Cylinders | Diesel | G9U 720 |
| INTERSTAR Pianale piatto/Telaio (X70) | 2004-02-01 - | 2463 cc | 73 KW | 99 HP | 4 Cylinders | Diesel | G9U 754 |
SCANIA
SCANIA G I
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| G I | 2012-09-01 - 2019-05-01 | 12742 cc | 302 KW | 411 HP | Cylinders |
SCANIA P I
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| P I | 2011-01-01 - 2019-05-01 | 12742 cc | 302 KW | 411 HP | Cylinders | ||
| P I | 2013-09-01 - 2019-05-01 | 12742 cc | 302 KW | 411 HP | Cylinders |
SCANIA R I
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| R I | 2012-09-01 - 2019-05-01 | 12742 cc | 302 KW | 411 HP | Cylinders |
Techinical Info
The control unit Scania OE 3007936 is an engine management module (ECU/EMS) used on Euro 6 applications, typically paired with engines from the DC13 family. In practice it is the unit that coordinates fueling, combustion strategies and emission control functions, communicating with the rest of the vehicle via the CAN network.
Technical specifications
- Module type: engine management control unit EMS family S8
- Vehicle electrical architecture: nominal supply 24 V
- Communication network: CAN High / CAN Low
- Typical power lines: terminal 30 (+battery) and terminal 15 (ignition-switched) with dedicated fuse protection
- Environmental robustness: high protection rating when connectors are correctly inserted and tightened
DIPA can intervene to overhaul these components thanks to its experience and expertise.
Functions
- Injection management (actuator control, quantity/timing, torque strategies and limitations)
- Idle control, starting, speed stabilization and anti-stall
- Supervision of engine sensors (speed/phase, pressures, temperatures, intake air, etc.) with plausibility checks and diagnostics
- Management of emission systems (logic related to EGR and aftertreatment, where present)
- Management of emergency modes and protection strategies
- Communication with diagnostic tools and other control units (status exchange, torque requests, fault reporting)
Applications
- Scania series P/G/R/T
Typical faults
- No communication with the diagnostic tool
- No start or irregular starting
- Engine starts, but no response to throttle input
- Hot shutdowns or intermittent operation
- The control unit goes into protection mode
Final conclusions
The Scania OE 3007936 belongs to the S8 family of engine management control units for Euro 6 applications.
DIPA has a wide range of spare parts dedicated to the world of Truck, construction vehicles and industrial equipment. Not only that: it offers remanufactured components with performance equivalent to new, which can provide savings on replacement while contributing to environmental protection through the circular economy. If the spare part you need is not available, don’t worry: DIPA can overhaul your part "on demand", restoring full functionality and safety in a short time.
