Ecu Temic Mercedes Truck Actros Atego
- DiPa Code:
- EDTEMIC006R
- OEM Code:
- 350341
- Brand:
- DIPA SPORT
- Cod.Cross:
- Condition:
- Remanufactured
Typical Errors and Defects
Typical Defects:
Failure to start one or more banks
Error Codes:
24906 - Ground return in bank 2
Applications
FIAT
FIAT DUCATO Autobus (250_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| DUCATO Autobus (250_), DUCATO Autobus (250_, 560_) | 2010-04-01 - | 2999 cc | 107 KW | 146 HP | 4 Cylinders | Diesel | F1CE3481N |
MERCEDES-BENZ
MERCEDES-BENZ ACTROS MP4 / MP5
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| ACTROS MP4 / MP5 | 2011-07-01 - | 7698 cc | 175 KW | 238 HP | Cylinders | ||
| ACTROS MP4 / MP5 | 2013-05-01 - | 7698 cc | 175 KW | 238 HP | Cylinders |
MERCEDES-BENZ ATEGO 2
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| ATEGO 2 | 2004-10-01 - | 6374 cc | 175 KW | 238 HP | Cylinders | ||
| ATEGO 2 | 2004-10-01 - | 7201 cc | 175 KW | 238 HP | Cylinders |
MERCEDES-BENZ ATEGO 3
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| ATEGO 3 | 2013-04-01 - | 7698 cc | 175 KW | 238 HP | Cylinders | ||
| ATEGO 3 | 2013-05-01 - | 7698 cc | 175 KW | 238 HP | Cylinders | ||
| ATEGO 3 | 2017-04-01 - | 7698 cc | 175 KW | 238 HP | Cylinders | ||
| ATEGO 3 | 2022-01-01 - | 7698 cc | 175 KW | 238 HP | Cylinders |
PEUGEOT
PEUGEOT J7 Furgone
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| J7 Furgone | 1968-08-01 - 1978-07-01 | 1948 cc | 40 KW | 55 HP | 4 Cylinders | Diesel | XDP 88 |
| J7 Furgone | 1970-07-01 - 1980-03-01 | 1796 cc | 48 KW | 65 HP | 4 Cylinders | Gasoline | XM7P |
Techinical Info
The control unit Mercedes OE A0694474340 is commonly identified as the Temic PLD control unit (Pumpe-Leitung-Düse), used on several Mercedes-Benz commercial vehicles with a PLD diesel injection architecture. In this configuration the PLD manages the electrical control of the injection units and the supervision of their circuits, operating within the engine management strategy defined for that specific vehicle, engine and software variant. In practice: the pump generates high pressure, sends it through a short line and the injector atomizes it into the combustion chamber.
Technical characteristics
- Type: PLD control unit for unit pump / PLD injection systems
- Manufacturer: Temic
- Vehicle architecture: 24 V system
- System interface: multipolar connectors; (55-pin and a 16-pin connector)
DIPA can intervene to overhaul these components thanks to its experience and expertise.
Functions
- Electrical control of the injection units in PLD architecture (control of the solenoids/actuators of the unit pumps according to the engine strategy)
- Monitoring and diagnostics of the control circuits and electrical feedback of the injection units
- Management of safety conditions in case of faults
Model applications
- Mercedes-Benz Actros MP2/MP3/Atego
Common faults
- Failure to ignite one or more cylinder banks
Error Codes
24906 - Ground return in bank 2
Final conclusions
The Mercedes OE A0694474340 is a Temic PLD control unit intended for PLD/unit pump injection systems on various Mercedes commercial vehicles.
DIPA has a wide range of spare parts dedicated to the Truck sector, construction vehicles and industrial equipment. Not only that: it offers reconditioned components with performance equivalent to new, which can achieve cost savings on replacement while contributing to environmental protection through the circular economy. If the spare part you need is not available, don't worry: DIPA can recondition your part "on demand", restoring its full functionality and safety in a short time.
