Headlight ECU ballast for Scania R Series
- DiPa Code:
- LTX116R
- OEM Code:
- 1746876
- Brand:
- PHILIPS
- Cod.Cross:
- Condition:
- Remanufactured
Overhaul of the control unit for xenon lamp
Typical Errors and Defects
Typical defects: Headlight does not light; intermittent illumination or flickering; turns off after a short time; warning light on the instrument cluster
Applications
ALFA ROMEO
ALFA ROMEO AR 6 Furgone (280_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| AR 6 Furgone (280_) | 1985-04-01 - 1989-12-01 | 1929 cc | 51 KW | 69 HP | 4 Cylinders | Diesel | 160 D100 |
ALFA ROMEO ROMEO 2 Autobus (T10_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| ROMEO 2 Autobus (T10_) | 1956-01-01 - 1967-12-01 | 1158 cc | 31 KW | 42 HP | 2 Cylinders | Diesel | XDP13 |
ALFA ROMEO ROMEO 2 Furgone (T10_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| ROMEO 2 Furgone (T10_) | 1956-01-01 - 1967-12-01 | 1158 cc | 31 KW | 42 HP | 2 Cylinders | Diesel | XDP13 |
FIAT
FIAT DOBLO Cassone/Limousine spaziosa (223_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| DOBLO Cassone/Limousine spaziosa (223_), DOBLO MONOCAB (223_) | 2003-07-01 - | 1910 cc | 77 KW | 105 HP | 4 Cylinders | Diesel | 223 A7.000 |
| DOBLO Cassone/Limousine spaziosa (223_), DOBLO MONOCAB (223_) | 2003-07-01 - | 1910 cc | 77 KW | 105 HP | 4 Cylinders | Diesel | 223 B1.000 |
KARRY
KARRY YOUSHENG I
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| YOUSHENG I | 2010-03-01 - 2013-12-01 | 1083 cc | 55 KW | 75 HP | 4 Cylinders | Gasoline | SQR472WF |
| YOUSHENG I | 2010-03-01 - 2013-12-01 | 999 cc | 50 KW | 68 HP | 4 Cylinders | Gasoline | SQR472WC |
NISSAN
NISSAN INTERSTAR Autobus (X70)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| INTERSTAR Autobus (X70) | 2006-04-01 - 2011-03-01 | 2463 cc | 74 KW | 101 HP | 4 Cylinders | Diesel | G9U 650 |
NISSAN INTERSTAR Furgone (X70)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| INTERSTAR Furgone (X70) | 2006-04-01 - | 2463 cc | 74 KW | 101 HP | 4 Cylinders | Diesel | G9U 720 |
| INTERSTAR Furgone (X70) | 2006-04-01 - | 2463 cc | 74 KW | 101 HP | 4 Cylinders | Diesel | G9U 754 |
NISSAN INTERSTAR Pianale piatto/Telaio (X70)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| INTERSTAR Pianale piatto/Telaio (X70) | 2003-08-01 - | 2463 cc | 84 KW | 115 HP | 4 Cylinders | Diesel | G9U 720 |
| INTERSTAR Pianale piatto/Telaio (X70) | 2003-08-01 - | 2463 cc | 84 KW | 115 HP | 4 Cylinders | Diesel | G9U 754 |
| INTERSTAR Pianale piatto/Telaio (X70) | 2003-08-01 - | 2463 cc | 84 KW | 115 HP | 4 Cylinders | Diesel | G9U 724 |
| INTERSTAR Pianale piatto/Telaio (X70) | 2003-08-01 - | 2463 cc | 84 KW | 115 HP | 4 Cylinders | Diesel | G9U 750 |
| INTERSTAR Pianale piatto/Telaio (X70) | 2004-02-01 - | 2463 cc | 73 KW | 99 HP | 4 Cylinders | Diesel | G9U 720 |
| INTERSTAR Pianale piatto/Telaio (X70) | 2004-02-01 - | 2463 cc | 73 KW | 99 HP | 4 Cylinders | Diesel | G9U 754 |
OPEL
OPEL CORSA A Furgone/hatchback (S83)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| CORSA A Furgone/hatchback (S83) | 1986-02-01 - 1990-07-01 | 1196 cc | 44 KW | 60 HP | 4 Cylinders | Gasoline | 12 S |
OPEL KADETT E Furgone/familiare (T85)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| KADETT E Furgone/familiare (T85) | 1984-09-01 - 1989-07-01 | 1297 cc | 44 KW | 60 HP | 4 Cylinders | Gasoline | 13 N |
| KADETT E Furgone/familiare (T85) | 1984-09-01 - 1989-07-01 | 1297 cc | 44 KW | 60 HP | 4 Cylinders | Gasoline | 13 NB |
| KADETT E Furgone/familiare (T85) | 1989-08-01 - 1993-09-01 | 1598 cc | 55 KW | 75 HP | 4 Cylinders | Gasoline | C 16 NZ |
RENAULT, RENAULT KOREA
RENAULT, RENAULT KOREA 19 I Furgone/hatchback (S53_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| 19 I Furgone/hatchback (S53_), 19 Furgone/hatchback (S53_) | 1988-01-01 - 1992-12-01 | 1870 cc | 48 KW | 65 HP | 4 Cylinders | Diesel | F8Q 742 |
| 19 I Furgone/hatchback (S53_), 19 Furgone/hatchback (S53_) | 1988-01-01 - 1992-12-01 | 1870 cc | 48 KW | 65 HP | 4 Cylinders | Diesel | F8Q 706 |
| 19 I Furgone/hatchback (S53_), 19 Furgone/hatchback (S53_) | 1988-01-01 - 1992-12-01 | 1390 cc | 59 KW | 80 HP | 4 Cylinders | Gasoline | E6J 700 |
| 19 I Furgone/hatchback (S53_), 19 Furgone/hatchback (S53_) | 1988-01-01 - 1992-12-01 | 1237 cc | 40 KW | 54 HP | 4 Cylinders | Gasoline | C1G 730 |
RENAULT, RENAULT KOREA 19 II Furgone/hatchback (S53_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| 19 II Furgone/hatchback (S53_), 19 Mk II Furgone/hatchback (S53_) | 1992-03-01 - 1995-12-01 | 1870 cc | 48 KW | 65 HP | 4 Cylinders | Diesel | F8Q 742 |
| 19 II Furgone/hatchback (S53_), 19 Mk II Furgone/hatchback (S53_) | 1992-03-01 - 1995-12-01 | 1870 cc | 68 KW | 92 HP | 4 Cylinders | Diesel | F8Q 740 |
| 19 II Furgone/hatchback (S53_), 19 Mk II Furgone/hatchback (S53_) | 1992-03-01 - 1995-12-01 | 1870 cc | 48 KW | 65 HP | 4 Cylinders | Diesel | F8Q 706 |
RENAULT, RENAULT KOREA 21 Furgone/familiare (S48_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| 21 Furgone/familiare (S48_) | 1986-06-01 - 1994-08-01 | 1870 cc | 47 KW | 64 HP | 4 Cylinders | Diesel | F8Q 710 |
SCANIA
SCANIA R I
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| R I | 2003-01-01 - 2019-05-01 | 12742 cc | 331 KW | 450 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 426 KW | 580 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 426 KW | 579 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 455 KW | 619 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 411 KW | 559 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 456 KW | 620 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 412 KW | 560 HP | Cylinders | ||
| R I | 2004-03-01 - 2019-05-01 | 15607 cc | 368 KW | 500 HP | Cylinders | ||
| R I | 2004-04-01 - 2019-05-01 | 12742 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2004-04-01 - 2019-05-01 | 15607 cc | 412 KW | 560 HP | Cylinders | ||
| R I | 2004-04-01 - 2019-05-01 | 15607 cc | 426 KW | 580 HP | Cylinders | ||
| R I | 2004-04-01 - 2019-05-01 | 15607 cc | 368 KW | 500 HP | Cylinders | ||
| R I | 2004-06-01 - 2019-05-01 | 11705 cc | 345 KW | 469 HP | Cylinders | ||
| R I | 2004-06-01 - 2019-05-01 | 11705 cc | 279 KW | 379 HP | Cylinders | ||
| R I | 2004-06-01 - 2019-05-01 | 11705 cc | 309 KW | 420 HP | Cylinders | ||
| R I | 2004-06-01 - 2019-05-01 | 11705 cc | 324 KW | 441 HP | Cylinders | ||
| R I | 2004-07-01 - 2019-05-01 | 12742 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2004-09-01 - 2019-05-01 | 15607 cc | 412 KW | 560 HP | Cylinders | ||
| R I | 2004-10-01 - 2019-05-01 | 15607 cc | 456 KW | 620 HP | Cylinders | ||
| R I | 2005-09-01 - 2019-05-01 | 15607 cc | 456 KW | 620 HP | Cylinders | ||
| R I | 2005-09-01 - 2019-05-01 | 11705 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2005-09-01 - 2019-05-01 | 11705 cc | 250 KW | 340 HP | Cylinders | ||
| R I | 2006-09-01 - 2019-05-01 | 15607 cc | 412 KW | 560 HP | Cylinders | ||
| R I | 2006-11-01 - 2019-05-01 | 15607 cc | 456 KW | 620 HP | Cylinders | ||
| R I | 2007-09-01 - 2019-05-01 | 12742 cc | 265 KW | 360 HP | Cylinders | ||
| R I | 2007-09-01 - 2019-05-01 | 12742 cc | 294 KW | 400 HP | Cylinders | ||
| R I | 2007-09-01 - 2019-05-01 | 12742 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2007-09-01 - 2019-05-01 | 12742 cc | 346 KW | 470 HP | Cylinders | ||
| R I | 2007-09-01 - 2019-05-01 | 12742 cc | 324 KW | 441 HP | Cylinders | ||
| R I | 2007-09-01 - 2019-05-01 | 12742 cc | 309 KW | 420 HP | Cylinders | ||
| R I | 2008-01-01 - 2019-05-01 | 15607 cc | 368 KW | 500 HP | Cylinders | ||
| R I | 2008-03-01 - 2019-05-01 | 15607 cc | 456 KW | 620 HP | Cylinders | ||
| R I | 2008-03-01 - 2019-05-01 | 15607 cc | 412 KW | 560 HP | Cylinders | ||
| R I | 2009-03-01 - 2019-05-01 | 15607 cc | 368 KW | 500 HP | Cylinders | ||
| R I | 2009-03-01 - 2019-05-01 | 15607 cc | 456 KW | 620 HP | Cylinders | ||
| R I | 2009-03-01 - 2019-05-01 | 15607 cc | 412 KW | 560 HP | Cylinders | ||
| R I | 2010-04-01 - 2019-05-01 | 12742 cc | 265 KW | 360 HP | Cylinders | ||
| R I | 2010-04-01 - 2019-05-01 | 12742 cc | 294 KW | 400 HP | Cylinders | ||
| R I | 2010-04-01 - 2019-05-01 | 12742 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2010-04-01 - 2019-05-01 | 12742 cc | 324 KW | 440 HP | Cylinders | ||
| R I | 2010-10-01 - 2019-05-01 | 12742 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2011-01-01 - 2019-05-01 | 12742 cc | 338 KW | 460 HP | Cylinders | ||
| R I | 2012-01-01 - 2019-05-01 | 12742 cc | 324 KW | 440 HP | Cylinders | ||
| R I | 2012-01-01 - 2019-05-01 | 12742 cc | 353 KW | 480 HP | Cylinders | ||
| R I | 2012-09-01 - 2019-05-01 | 12742 cc | 302 KW | 411 HP | Cylinders | ||
| R I | 2012-09-01 - 2019-05-01 | 12742 cc | 360 KW | 489 HP | Cylinders | ||
| R I | 2012-09-01 - 2019-05-01 | 12742 cc | 272 KW | 370 HP | Cylinders | ||
| R I | 2012-09-01 - 2019-05-01 | 12742 cc | 360 KW | 490 HP | Cylinders | ||
| R I | 2012-09-01 - 2019-05-01 | 12742 cc | 331 KW | 450 HP | Cylinders | ||
| R I | 2012-10-01 - 2019-05-01 | 12742 cc | 324 KW | 441 HP | Cylinders | ||
| R I | 2013-09-01 - 2019-05-01 | 12742 cc | 331 KW | 450 HP | Cylinders |
VAUXHALL
VAUXHALL MOVANO Mk I (A) Combi (X70)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| MOVANO Mk I (A) Combi (X70) | 2001-10-01 - 2009-08-01 | 2463 cc | 74 KW | 101 HP | 4 Cylinders | Diesel | G9U 650 |
VW
VW CADDY II Cassone/Limousine spaziosa (9K9A)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| CADDY II Cassone/Limousine spaziosa (9K9A), PANEL II Cassone/Limousine spaziosa (9K9A), VAN II Cassone/Limousine spaziosa (9K9A) | 1995-11-01 - 2004-01-01 | 1896 cc | 47 KW | 64 HP | 4 Cylinders | Diesel | 1Y |
VW TRANSPORTER T3 Furgone (24_, 25_)
| Model | Year of Production | Displacement | KW | HP | Cylinders | Fuel Type | Engine Code |
|---|---|---|---|---|---|---|---|
| TRANSPORTER / KOMBI T3 Furgone (24_, 25_), TRANSPORTER T3 Furgone (24_, 25_), VANAGON T3 Furgone (24_, 25_) | 1984-10-01 - 1989-02-01 | 1913 cc | 61 KW | 83 HP | 4 Cylinders | Gasoline | DH |
Techinical Info
The SCANIA component with OE code 1746876 is the control unit for Xenon headlights (called a ballast) fitted on some Scania vehicles, integrated into the headlamp assembly. Its main function is to manage the ignition and stable operation of the Xenon lamp, generating the high ignition voltage and regulating power during operation.
In practice, when the unit is faulty or operating out of specification, the headlight may fail to light, flicker, switch off when hot, or trigger dashboard warnings related to the main headlight malfunction.
Technical specifications
- Nominal supply 24 V.
- Power control unit for 35 W HID lamps.
- Generation of the high starting voltage and management of the warm-up phase.
- Drive with an output waveform typically square wave and frequency on the order of hundreds of Hz.
- Typical internal protections: open circuit, short at the output, polarity reversal or start-up anomalies (depends on the version).
- Mounted on the headlamp with screw fastenings and a dedicated connector.
DIPA can intervene to overhaul these components thanks to its experience and expertise.
Functions
- Ignition of the Xenon lamp via a high-voltage ignition pulse.
- Stabilization of the lamp power after start-up to prevent flickering and shutdowns.
- Management of abnormal conditions (defective lamp, open circuit, short, overload), with protective shutdown when necessary.
- Interaction with vehicle diagnostics/instrumentation via headlight fault signals to the dashboard.
Model applications
- Scania series P/G/R/T
Common faults
- Headlight that does not turn on.
- Intermittent ignition or flickering.
- Switching off after a short time.
- Warning light illuminated on the dashboard.
Final conclusions
The SCANIA OE 1746876 is a 24 V Xenon headlight ballast for P/G/R/T series tractors: it generates the high ignition voltage and stabilizes the lamp operation.
DIPA has a wide range of spare parts dedicated to the agricultural world: from those for vehicles to those for auxiliary equipment. Moreover, it has refurbished components with performance equal to new, which can provide savings on replacement while contributing to environmental protection through the circular economy. If the spare part you need is not available, don't worry: DIPA can refurbish your part on demand, restoring its full functionality and safety in a short time.
